Pultrusion Machinery for Consistent Quality and Strength

When it comes to pultrusion machines, we stand out as the top choice for industries seeking high-quality, efficient, and durable solutions. Our machines are designed with the latest technology, offering superior performance and reliability to meet your production needs. With a strong focus on precision, our pultrusion machines deliver consistent results, producing high-strength composite materials with exceptional quality. We are committed to providing cutting-edge equipment that enhances your productivity and reduces operational costs.

Our pultrusion machines are engineered to handle various fiber types and resin formulations, offering flexibility and adaptability for diverse applications. Whether you're producing structural beams, rods, or custom components, our machines provide the versatility needed for consistent high-volume production. We also prioritize easy maintenance and long-lasting performance, ensuring minimal downtime and maximum output for your operations.

As leaders in the industry, we pride ourselves on providing unmatched customer support and tailored solutions. We understand the unique requirements of your business, and our team is dedicated to delivering a machine that meets your specific demands. Choose our pultrusion machines for exceptional efficiency, durability, and overall value. Let us help you take your production to the next level.

Benefits of Innomach Pultrusion Machine

Continuous Production

The machine enables uninterrupted manufacturing of long, uniform profiles with minimal intervention.

High Strength-to-Weight Ratio

Products are lightweight yet provide exceptional strength, making them ideal for structural applications.

Corrosion Resistance

Profiles produced resist corrosion, perfect for use in chemical plants, marine, and outdoor structures.

Custom Profiles

The machine supports complex cross-sectional shapes tailored to specific design and application needs.

Dimensional Accuracy

Advanced controls ensure consistent, precise dimensions in every profile manufactured.

Low Maintenance

Built for easy maintenance, reducing downtime and ensuring smooth, continuous production.

FRP

Pultrusion Machine

FRP

Pultrusion Machine

FRP

Pultrusion Machine

FRP

Pultrusion Machine

FRP Pultrusion
IE - 12P
IE - 20P
IE - 25P
Pulling Capacity (kgf)
12000
20000
25000
Useful Width Max (mm)
800
1000 - 1250
1000 - 1250
Useful Height Max (mm)
250 - 350
250 - 350
250 - 350
Pulling Speed (m/min)
40 - 1200
40 - 1100
40 - 1000
Clamping Length (mm)
500 - 600
500 - 600
500 - 600
Clamping Width (mm)
300 - 600
300 - 1250
300 - 1250
No.of Clampers/Puller
Single
Single / Double
Single / Double
Heating PID Controller Zones
9
9
9 to 20
Moving Puller Size (mm)
1000 X 500-650
*Customized Width
1200 X 500-650
*Customized Width
1200 X 500-650
*Customized Width
Puller Stroke (mm)
800
800
800
Die Clamping Area (LxW)
1200 - 1000
1200 - 1000
1400 - 1000
Require Electrical Power
10 KW
12 KW
12 - 20 KW
Actual Power Consumption
Excluding Heater Load
7.5 KW
10 KW
10 - 15 KW
Machine Dimensions (mtr)
6.5 X 1.4 X 1.8
8.5 X 1.4 X 1.8
8.5 X 1.6 X 1.8
Auto Cut Saw
Blade Radius
400
500 - 600
500 - 600
Motor Power (KW)
1.5
1.5 - 2.2
1.5 - 2.2
Air Flow
2 - 3 cfm
2 - 3 cfm
2 - 3 cfm
Pneumatic Puller
Actual Power Require
5 KW
8 KW
10 KW
Air Require for Puller @ 6 kg/cm2
4 - 6 cfm
6 - 8 cfm
6 - 8 cfm

WHY CHOOSE INNOMACH?

Your Trusted Partner for
High-Performance Pultrusion Machines

At Innomach, we are committed to providing top-quality pultrusion machines that offer unmatched performance, efficiency, and durability. Here are a few reasons why we are the best choice for your manufacturing needs:

  • With years of experience, we understand the specific demands of various industries & provide solutions to meet your exact needs.
  • Our machines incorporate the latest technology to ensure precision, high efficiency, and long-lasting performance, giving you a competitive edge.
  • We offer flexible solutions designed to fit a variety of product profiles and production volumes, ensuring a perfect fit for your business.
  • Our machines are designed to reduce operational costs while improving productivity, helping you maximize your return on investment.
  • We provide comprehensive support, from machine installation to training & maintenance, ensuring smooth operations all times.
  • We provide strong post-sale support, ensuring smooth operation and addressing any concerns you may have.
